AT930

AT930 Laser Tracker




AT930 Laser Tracker:

The Leica Absolute Tracker AT930 is a cutting-edge 3D laser tracker with the Leica Absolute Interferometer (AIFM) for superior high-speed dynamic measurements. It boasts automatic target location, real-time architecture, and can swiftly recover from interrupted beams. Meeting IP54 IEC standards, the AT930 is built for challenging conditions without requiring extra accessories. Essentially the 3D counterpart to the AT960, it excels in high-speed measurements up to 160 m (Ø) and works seamlessly with reflectors. Notable features include PowerLock's advanced vision system, laser auto-follow, a measurement rate of 1,000 points/second, and a built-in overview camera. Designed for portability, it comes with wireless connectivity and options for mains or battery power. Just unpack and measure virtually anywhere.

Features & Benefits of the AT930 Leica Laser Tracker:

  • All-in-one Design: Built-in accessories for quick setup, minimal training, and immediate measuring.

  • PowerLock: Auto-restores interrupted line of sight within +/-5 degrees, ensuring continuous tracking even in crowded areas.

  • Absolute Interferometer (AIFM): Merges absolute distance meter's accuracy with interferometer's speed, eliminating the need for a home point.

  • 1 kHz Data Output: Real-time architecture offers up to 1,000 points/sec measurement rate for faster, detailed data capture.

  • Battery Power: Cable-free setup with a hot-swap battery that lasts an entire shift, enhancing portability.

  • Wi-Fi: Inbuilt Wi-Fi for wireless operations, PC communication, and remote control via various devices, supporting single-user operation.

  • IP54: IEC-certified protection against dust and contaminants, ensuring reliable measurements in challenging environments.

  • MeteoStation: Monitors environmental conditions like temperature and humidity, adjusting for accurate measurements.

  • Overview Camera (OVC): High-resolution camera for remote target viewing, aiding in locating fixed reflectors and documenting.

  • Orient to Gravity (OTG): Measures with Z-axis aligned to gravity, perfect for levelling and alignment tasks.
